Peptide Array
As a specialized Contract Manufacturing Organization (CMO), we offer top-tier peptide array solutions tailored for research and development needs across diverse applications. Our SPOT and CelluSPOT synthesis platforms enable the production of hundreds of peptides on a membrane, making it ideal for high-throughput and precise screening assays.
With our peptide arrays, you can conduct a wide range of studies, from epitope mapping and kinase mapping to protein interaction assays. Optimize binding interactions, conduct immune-screenings, and drive discovery with unparalleled accuracy and flexibility. Let us support your research with innovative peptide solutions that deliver results.
Screening of
Epitopes
Protein-protein/peptide interaction
Receptor-ligand interaction
Enzyme-substrate specificity
Our offering
BLOT Arrays
- Robust technology
- Up to 600 spots per Membrane
- Compatible with flatbed scanners
- Reusable
- Peptides bound via CT
CelluSpot Arrays
- Up to 768 spots
- Custom synthesis
- Microscope slides
- Wide range of modifications possible
Our service
1. Initial consulting
We will evaluate your peptide arrays on feasibility and physical properties to ensure high success rates. Also we can support you in designing your peptide arrays according to your research aims.
2. Fast turn-around times
From order to delivery we can be as fast as 2 weeks, depending on the number of peptides, number of arrays and length of peptides. You will receive a delivery time estimate with your quote.
3. Continuous Feedback
You will receive regular updates on the status of your peptide array project.
4. CoA and documentation
With your peptide array, you will receive a manual of how to effectively use peptide arrays.
Peptide Arrays Modifications
If you cannot find a modification, please reach out to us. We will make it possible.
| Amino Acid |
|---|
| (L)-Phospho amino acids |
| (D)-Amino acids |
| Heavy isotope amino acids |
| 8-Amino-3,6-dioxaoctanoic acid |
| 6-Aminohexanoic acid |
| 2-Aminobutanoic acid |
| (L)-Lys(Ac)- |
| (L)-Glyco amino acids |
| (L)-Cys(Carboxamidomethyl)- |
| (L)-Arg(Me)2symm. |
| (L)-Arg(Me)2asymm. |
| (L)-Lys(Me)3– |
| (L)-Lys(Me)2– |
| (L)-Lys(Me)1– |
| Citrulline |
| Peptide | N-term |
|---|---|
| 5/6-FITC | ✓ |
| 5-FITC | ✓ |
| 5/6-Tamra | ✓ |
| Biotin | ✓ |
| Dinitrphenyl (DNP) | ✓ |
| Dabsyl (Dabs) | ✓ |
| Dabsyl (Dans) | ✓ |
| Methoxycoumarinacetyl (MCA) | ✓ |
| Maleimidopropionyl- | ✓ |
| Azidohexanoyl- | ✓ |
| Cy-5 | ✓ |
| Dyomics dyes | ✓ |
| Alexa Fluor® dyes | ✓ |
| 5/6-FAM | ✓ |
| 5-FAM | ✓ |
| Sulfated peptides |
Frequently asked Questions
We can synthesize up to 600 peptide spots per cellulose membrane.
The standard format is 100x150mm with 5 spots per cm² and spot diameter of approx. 2-3 mm.
Yes, they are covalently bound through the C-terminus via an amide bond to amine-functionalized membrane.
Per spot, there are about 5-10 nmol peptide immobilized on the membrane.
SPOT peptide arrays are commonly used in epitope or kinase mapping, protein interaction assays, binding optimization studies and immune screenings.
Yes, they can be reused to a certain extent, but be aware that this may have an impact on the result of your assay. A membrane stripping-protocol can be requested from us.
Yes, they can be scanned by those and are BLOT-compatible.
Order your peptides
Click order and a form will pop-up so you can enter your sequence directly. Alternatively upload a document listing your peptides or conjugates.
